Wooden laminated scantlings for solid or mixed windows, with guaranteed stability and durability
Available in oak, beech and pine
Grupo Gámiz laminated scantlings are an excellent option for manufacturers of doors, windows and joinery in general.
In addition to the strict quality levels we demand from our products, our laminated scantlings are endorsed by the prestigious French centre FCBA, dedicated to research, innovation and knowledge transfer in the wood, construction and furniture sectors and the forestry industry.
The result is the full guarantee of our laminated scantlings in terms of finish quality, and its thermal insulation capacity in the construction of solid or mixed (aluminium and wood) doors and windows.
Make your order your way
We’ll adapt to your needs
- Full scantlings with spliced staves (KKK)
- With all full staves (DDD)
- Full staves with the two outer faces with full staves and the interior with the finger joint system (DKD)
- Possibility moulded and veneered scantlings
- Tell us your specific needs
Datasheet
| CHARACTERISTICS | PERFORMANCE |
|---|---|
| Type of laminated scantling | DDD / DKD / KKK (D = full stave; K = spliced staves) |
| Species | Oak / beech / pine (ask us for other species) |
| Gluing | D4 in accordance with EN 204 with water-resistant glues |
| Qualities | A or B (ask us for other qualities) |
| Length | Máx. 6.000 mm |
| Widths | 63/72/85/95/105/115/125/145 mm (ask us for other widths) |
| Thicknesses | 63/72/84 mm (ask us for other thicknesses) |
| Wood moisture content | 12% (± 2%) |
